CNC Slant Bed Lathe with Servo Turret and Hydraulic Tailstock

CNC Slant Bed Lathe with Servo Turret and Hydraulic Tailstock (model YL-46K) is a precision turning machine manufactured by Quanzhou Yueli Automation Equipment Co., Ltd. The 30-degree slant bed design provides rigidity and efficient chip removal during heavy cutting operations. Equipped with the FANUC Oi-TF PLUS (5) CNC system and Japan THK 32mm precision ball screws and 30mm linear roller guides, the machine delivers consistent accuracy and long-term stability. The 7.5KW Huahong spindle motor offers a speed range of 0 to 5000 RPM. The hydraulic tailstock with MT4 taper and 500mm travel supports stable workpiece holding, while the 63 servo turret enables automated tool changes for improved production efficiency.

Core Features

The CNC Slant Bed Lathe with Servo Turret and Hydraulic Tailstock offers the following key features.

· Slant Bed Design: 30-degree slant bed for enhanced rigidity and effective chip flow during machining.

· High-Precision Spindle: Cartridge-type precision spindle assembly with Japan NSK bearings. Spindle model A2-5 with 170mm diameter.

· Premium Guideways: Japan THK 30mm precision linear roller guides. X axis with 4 standard blocks, Z axis with 4 extended blocks.

· Precision Ball Screws: Japan THK 32mm ball screws with 10mm pitch for both X and Z axes.

· Servo Turret: 63 servo turret for rapid and accurate tool indexing.

· Hydraulic Tailstock: Linear guide tailstock with hydraulic propulsion. Tailstock travel 500mm with MT4 taper.

· Motor Drive System: Main spindle motor with belt drive, X and Z servo motors with direct drive connection.

Technical Specifications

The following table lists the complete technical parameters of the CNC Slant Bed Lathe with Servo Turret and Hydraulic Tailstock.

Machine Configuration

The CNC Slant Bed Lathe with Servo Turret and Hydraulic Tailstock is built with the following major components and brands.

· CNC System: FANUC Oi-TF PLUS (5) with FANUC X/Z servo motors and drives.

· Spindle Motor: Huahong 7.5KW.

· Ball Screws: Japan THK 32mm precision ball screws.

· Linear Roller Guides: Japan THK 30mm precision roller guides.

· Spindle Assembly: Cartridge precision type with Japan NSK bearings.

· Hydraulic Rotary Cylinder: Taiwan.

· Hydraulic Station: Taiwan.

· Power Head: 3-station, 11.4N.

· Coolant Pump: 750W.

Standard Accessories

Each CNC Slant Bed Lathe with Servo Turret and Hydraulic Tailstock comes with the following accessories.

· Spring collet for clamping material – 1 piece included.

· Turning tool holders – 3 pieces.

· Drilling tool holders – 2 pieces.

· Drilling tool bars – ER20A extension bar, 2 pieces.

· Hex key set – 1 set.

Applications and Advantages

The CNC Slant Bed Lathe with Servo Turret and Hydraulic Tailstock is suitable for a wide range of turning applications.

· Processing Capability: Maximum turning diameter 375mm, maximum machining length 380mm with chuck. Handles a variety of materials including steel, stainless steel, and non-ferrous metals.

· Production Efficiency: 63 servo turret enables rapid tool indexing, reducing setup time and increasing throughput for batch production.

· Precision and Stability: Japan THK guideways and ball screws, combined with FANUC CNC control, ensure consistent accuracy and repeatability.

· Workpiece Support: Hydraulic tailstock with 500mm travel and MT4 taper provides secure clamping for longer workpieces.

· Rigid Construction: 30-degree slant bed with heavy-duty roller guides supports stable heavy cutting operations.

Manufacturing and Quality Assurance

The CNC Slant Bed Lathe with Servo Turret and Hydraulic Tailstock is manufactured under strict quality control standards.

· All key components are sourced from established brands including FANUC, Japan THK, Japan NSK, and Huahong.

· Precision assembly processes for ball screws, linear guides, and spindle assemblies.

· Rigorous inspection and testing before delivery to ensure machine accuracy and reliability.

· Backed by more than ten years of manufacturing experience and professional technical support.

Frequently Asked Questions

What CNC system is used on this slant bed lathe?

The machine uses the FANUC Oi-TF PLUS (5) CNC system with FANUC servo motors and drives for X and Z axes.

What are the axis travels of this CNC lathe?

X axis travel is 200mm, and Z axis travel is 460mm.

What is the spindle speed and motor power?

Spindle speed ranges from 0 to 5000 RPM, powered by a 7.5KW Huahong spindle motor.

What type of guideways and ball screws are used?

The machine uses Japan THK 32mm precision ball screws and 30mm precision linear roller guides.

What is the machine weight and overall dimensions?

Machine dimensions are 1875×1021×1263mm, and weight is approximately 1.8 tons.
